SPECIFICATIONS

Adapting system: Android or iOS Harmony

Balance Function: Active Balanced BMS

Battery Strings: 7S/16S

Brand Name: JIKONG,JIKONG BMS

Certification: CE,FCC,RoHS,UL

Charge and Discharge Port: Common Port BMS

Charging Current: 200A

Firmware version: V19

Function: Overcharge Protection,Over Discharge Protection,Overcurrent Protection,Short Circuit Protection,Overcharge Protection,Over Discharge Protection,Overcurrent Protection,Short Circuit Protection

Handware or Smart: SMART BMS

High-concerned chemical: None

Origin: Mainland China

Other Features: Temperature protection/Heating Function/Support Parallel Connection

Supported interfaces: RS232/RS485/CAN/Uart

Type: LIFEPO4 Battery BMS,Li-ion / lifepo4 / LTO

Usage Scenario: Power BMS,Energy Storage BMS,3C Digital BMS

optional categories: 100A 150A 200A 300A Optional

Description

Product advantages:

◆New firmware version V19, improves stability and greatly reduces various failure rates

◆Active balance, good durability, long life, good balance, stable performance

◆Real-time active energy transfer balance with supercapacitor as medium (patent number: ZL 2019 2 0479589.6)

◆Single-channel voltage range 1V~5V, balance accuracy ±5mV

◆Can achieve 2-10A continuous balance current, ensure battery consistency, improve battery life, and delay battery aging.

◆Mobile phone Bluetooth communication, equipped with mobile phone APP, real-time battery status, support Android and IOS operating systems.

◆Applicable to lithium iron phosphate, ternary lithium, lithium titanate and other battery types.
