ECO-WORTHY 5000W Solar Hybrid Inverter 48V DC-120V/220V Pure Sine Wave Power Inverter AC Split Phase Off-Grid System
ECO-WORTHY 5000W Solar Hybrid Inverter 48V DC-120V/220V Pure Sine Wave Power Inverter AC Split Phase Off-Grid System
SPECIFICATIONS
Application: Home,Agriculture/Farming, Electronics, Home/Garden, Shed
Brand Name: ECO－WORTHY
Charging Mode: MPPT (Maximum Power Point Tracking)
Current Type: AC/DC
Features: Automatic Voltage Detection, LCD Display
High-concerned chemical: None
Inverter Technology: Battery-Based
Load Power (W): 5000W
Model Number: 1101800037
Origin: Mainland China
Output Voltage (V): 48V
Power Source: Solar
Protection Properties: Open Circuit Protection, Overcurrent Protection, Overload Protection, Overspeed Protection, Overvoltage Protection, Safety Circuit Protection, Short Circuit Protection
Solar Power (W): 6600W
Specification: Normal
System Configuration: Off-Grid
Type: Charger/Inverter
Wattage: 5000W
Work Time (h): 24
【Segmented Charing/Discharging】
3 output modes: mains priority and, battery priority, PV priority; uninterrupted power supply. Available in 4 charging modes: Only Solar, Mains Priority, Solar Priority and Mains & Solar hybrid charging. Set a flexible time period for mains charging/discharging according to the local mains condition, and help you save the mains.
【Technical Specifications】
Max.PV input power:6600W, PV input voltage range: 120-450V DC, Max.MPPT Charging Current:20A, Rated Output Power:5000W, Max.Peak Power:10000W, Rated Output Voltage:120/240Vac（split phase)
【Easy&Safe Use】
LCD display to monitor all data anytime. Multiple intelligent protections, such as PV input current/power limiting protection, PV input over-voltage, PV night reverse current protection, multiple cooling fans to prevent over-heat issue, etc.
